Description
The Huawei eKitEngine S220-48T4X is a Layer 2 Smart Managed Gigabit Switch designed for enterprise networks, SMBs, branch offices, educational institutions, hotels, retail stores, and campus environments. It features 48 Gigabit Ethernet RJ45 ports and 4 × 10GE SFP+ uplink ports, delivering reliable Gigabit access with high-speed 10 Gigabit fiber uplinks for aggregation and backbone connectivity.
The switch provides advanced Layer 2 networking features, including VLAN, QoS, ACL, Link Aggregation (LACP), STP/RSTP/MSTP, ERPS, IGMP Snooping, DHCP Snooping, IPv6, and comprehensive security mechanisms. These capabilities ensure efficient traffic management, network reliability, and secure access for business-critical applications.
Supporting Huawei eKit Cloud Management, the S220-48T4X enables centralized deployment, monitoring, configuration, and maintenance through the Huawei eKit App, Web GUI, CLI, and SNMP. This simplifies IT operations while improving network visibility and management efficiency.
With a built-in AC power supply, intelligent fan cooling, and a durable 1U metal rack-mount chassis, the S220-48T4X is an ideal solution for enterprise LANs, campus networks, data aggregation, and business environments requiring high-speed 10G fiber uplinks without PoE functionality. (ekit.huawei.com)
Specifications
| Feature | Specification |
|---|---|
| Model | Huawei eKitEngine S220-48T4X |
| Product Type | Layer 2 Smart Managed Gigabit Switch |
| Ethernet Ports | 48 × 10/100/1000BASE-T RJ45 |
| Uplink Ports | 4 × 10GE SFP+ |
| PoE Support | No |
| Switching Capacity | 176 Gbps |
| Packet Forwarding Rate | 131 Mpps |
| MAC Address Table | 16K Entries |
| VLAN Support | Up to 4,094 VLANs |
| QoS | Supported |
| ACL | Supported |
| Link Aggregation | LACP |
| Spanning Tree Protocol | STP, RSTP, MSTP |
| Ring Protection | ERPS |
| Multicast | IGMP Snooping |
| IPv6 | Supported |
| DHCP Features | DHCP Snooping |
| Management | Web GUI, CLI, SNMP, Huawei eKit App, Cloud Management |
| Power Supply | Built-in AC (90–290V AC, 45–65Hz) |
| Cooling | Intelligent Fan Cooling |
| Installation | Rack Mount, Desktop, Wall Mount |
| Chassis Material | Metal |
| Dimensions (H × W × D) | 43.6 × 442 × 220 mm |
| Weight | Approx. 2.7 kg |
| Operating Temperature | -5°C to +50°C |
