Description
AP361
Product description
WiFi access point HUAWEI ensures immediate access to the Internet for all individual devices thanks to MU-MIMO technology. It works in two frequency bands, which ensures ideal flexibility and performance for a typical home network. With a WiFi transfer speed of 2975 Mb/s, you can count on your connection to be fast enough. The AP has WiFi 6 technology. This device is capable of working on the 2.4 GHz and 5 GHz frequency bands. Data transfer security is achieved through WPA2, WPA2-PSK, WPA2-Enterprise and WPA3 encryption. Access point HUAWEI will provide you with a connection to the digital world.
Dual-band radio that boasts 2×2 MU-MIMO & OFDMA (5GHz) and 2×2 MIMO (2.4GHz)
AP361 Key Features
- Wi-Fi 6 technology
- 5GHz throughput up to 2400Mbps
- 2.4GHz throughput up to 575Mbps
- 802.3af POE power supply
- WPA3 security
Cloud management
AP supports cloud management. It provides various authentication functions such as PSK, portal, SMS and social authentication without the need to use WAC or authentication server. This greatly simplifies network work and reduces infrastructure investment. In addition, the AP access point can be deployed on a cloud-based management platform to realize cloud-based network planning, deployment, control, operation and maintenance. In cases of multi-site deployment, after pre-configuration in the cloud, it is enough to install on site and just connect to the network. Then scan their QR codes for plug-and-play. Configurations will automatically start downloading to the AP. This mode significantly speeds up network deployment. Thanks to the cloud, you can also monitor several individual networks.
Package contents
- Device
Technical parameters
AP361
Wireless features
- Frequency range [MHz] : 2412 – 2472, 5180 – 5825
- Wireless frequency : 2.4 + 5 GHz (dual band)
- WiFi standards : 802.11ax, 802.11ac, 802.11ac – wave2, 802.11n, 802.11a, 802.11b/g
- MU-MIMO : Yes
- Transmission speed – 5GHz [Mb/s] : 1201
- Transmission speed – 2.4GHz [Mb/s] : 574
- Tx power 2.4GHz [dBm] : 20
- Tx power 5GHz [dBm] : 20
- Security : WEP, WPA, WPA2, WPA3
- 2.4GHz MIMO : 2 x 2
- 5GHz MIMO : 2 x 2
- Type of antenna : Built-in
- Internal antennas : 4
- Antenna gain [dBi] : 4, 5
Connectors and Interfaces
- LAN speed : (1) 10/100/1000Mbps
- Gigabit LAN : Yes
Power
- Power over Ethernet : 802.3af
- PoE type: PoE-In (only)
- Max. power consumption [W] : 8,8
Physical characteristics
- Purpose : Indoor
- Operating temperature [°C] : -10 up to 50
- Weight [g] : 450
- Width [mm] : 180
- Height [mm] : 35
- Depth [mm] : 180
Hardware
- CPU : Dual Core
- CPU frequency [MHz] : 1000
- RAM [MB] : 512
Software
- Operating mode : Access Point
