Description
S310S-24T4J
| Specification | Details |
|---|
| Model | S310S-24T4J |
| Switch Type | Managed |
| Switch Layer | L2+ |
| Ports | – 24 × 10/100/1000BASE-T (RJ-45) ports – 4 × 2.5GE SFP ports |
| MAC Address Table | 16,000 entries |
| Switching Capacity | 68 Gbit/s |
| Forwarding Rate | 51 Mpps |
| Networking Standards | IEEE 802.1D, IEEE 802.1s, IEEE 802.1w |
| VLAN Support | Up to 4,096 VLANs |
| Quality of Service (QoS) | Supported |
| Management Features | Web-based management, Cloud-managed |
| Security Features | – DHCP client, DHCP snooping – Access Control List (ACL) – IGMP snooping – Security algorithms: HTTPS, SSH |
| Multicast Support | Supported |
| Dimensions without Packaging (H x W x D) | – Basic: 43.6 mm × 442 mm × 160 mm (1.72 in. × 17.40 in. × 6.30 in.) – Maximum: 43.6 mm × 442 mm × 167 mm (1.72 in. × 17.40 in. × 6.57 in.) |
| Dimensions with Packaging (H x W x D) | 90.0 mm × 550.0 mm × 260.0 mm (3.54 in. × 21.65 in. × 10.24 in.) |
| Chassis Height | 1U |
| Chassis Material | Metal |
| Installation Type | Rack mounting, Desk mounting, Wall mounting |
| Weight without Packaging | 1.97 kg (4.34 lb) |
| Weight with Packaging | 2.76 kg (6.08 lb) |
| Typical Power Consumption | 21.32 W |
| Typical Heat Dissipation | 72.75 BTU/hour |
| Maximum Power Consumption | 21.9 W |
| Maximum Heat Dissipation | 74.72 BTU/hour |
| Static Power Consumption | 11.14 W |
| MTBF (Mean Time Between Failures) | 59.31 years |
| MTTR (Mean Time To Repair) | 2 hours |
| Availability | > 0.99999 |
| Long-term Operating Temperature | –5°C to +40°C (41°F to 104°F) at 0–1800 m (0–5905.44 ft.) |
| Operating Temperature Variation Rate Restriction | Above 1800 m (5906 ft.) up to 5000 m (16404 ft.), decrease max operating temp by 1°C per 220 m |
| Storage Temperature | –40°C to +70°C (–40°F to +158°F) |
| Long-term Operating Relative Humidity | 5% RH to 95% RH (non-condensing) |
| Long-term Operating Altitude | 0–5000 m (0–16404 ft.) |
| Storage Altitude | 0–5000 m (0–16404 ft.) |
| Power Supply Mode | AC built-in |
| Rated Input Voltage | 100–240 V AC; 50/60 Hz |
| Input Voltage Range | 90 V AC to 264 V AC; 45 Hz to 65 Hz |
| Maximum Input Current | 0.8 A |
| Power Supply Surge Protection | ±4 kV in differential mode and ±4 kV in common mode |
| Ingress Protection Level (Dustproof/Waterproof) | IP20 |
| Heat Dissipation Mode | Natural heat dissipation |
| Form Factor | 1U |
| Color | Grey |
| LED Indicators | Supported |
| Power Source | AC |
| Power Supply Included | Yes |
| Number of Power Supply Units | 1 |
| Power Connector | AC-in jack |
| Power over Ethernet (PoE) | Not supported |
