Description
R4W04A
R4W04A Specification |
|
|
General |
|
|
Device Type |
Wireless access point |
|
Ruggedized Design |
Indoor |
|
Width |
16 cm |
|
Depth |
16 cm |
|
Height |
3.7 cm |
|
Networking |
|
|
Form Factor |
Wall / ceiling mountable |
|
Connectivity Technology |
Wireless |
|
Line Coding Format |
1024 QAM |
|
Data Link Protocol |
Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6) |
|
Spread Spectrum Method |
OFDMA |
|
Network / Transport Protocol |
PPPoE |
|
Frequency Band |
2.4 GHz, 5 GHz |
|
Performance |
Maximum data rate (5 GHz): 1.2 Gbps Maximum data rate (2.4 GHz): 574 Mbps |
|
Status Indicators |
Status |
|
Encryption Algorithm |
WPA2, WPA3 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6 |
| Antenna | |
| Antenna | Internal |
| Directivity | Omni-directional |
| Internet of Things (IoT) | |
| Internet of Things (IoT) Compatible | Yes |
| Communications Technology | Bluetooth Low Energy (LE) |
| Expansion / Connectivity | |
|
Interfaces |
1 x Ethernet 1000 (uplink) |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Software / System Requirements | |
| Software Included | InstantOn |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature |
40 °C |
