Description
IPC323LB-SF28K-G
The IPC3613LB-AF28K-G is a 3-megapixel (3MP) fixed eyeball network camera from Uniview, designed to deliver high-quality video surveillance with advanced features. Below is an overview of its specifications:
Camera Specifications:
- Image Sensor: 1/2.7″ Progressive Scan CMOS
- Maximum Resolution: 3MP (2304×1296)
- Frame Rate: Up to 30 frames per second (fps) at 3MP resolution
- Lens: 2.8mm fixed lens
- Field of View (FOV):
- Horizontal: 105°
- Vertical: 56°
- Diagonal: 125°
- Day/Night Functionality: Automatic switching with Smart IR
- Infrared (IR) Range: Up to 30 meters (98 feet)
- Wide Dynamic Range (WDR): 120dB
- Digital Noise Reduction (DNR): 2D/3D DNR
Video Compression:
- Formats Supported: Ultra 265, H.265, H.264, MJPEG
- Region of Interest (ROI): Up to 8 areas
- Corridor Mode: Supports 9:16 aspect ratio for vertical scenes
Audio:
- Built-in Microphone: Yes
Storage:
- Edge Storage: MicroSD card slot, supporting up to 128 GB
Network:
- Protocols Supported: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, HTTPS, QoS, SSL/TLS
- Integration Compatibility: ONVIF (Profile S, Profile T, Profile G), API, SDK
- User Access: Supports up to 32 users with 2 user levels: administrator and common user
- Security Features: Password protection, strong password enforcement, HTTPS encryption, exportable operation logs, basic and digest authentication for RTSP and HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
Interface:
- Network Interface: 1 × RJ45 10M/100M Base-TX Ethernet
Physical and Environmental:
- Power Supply:
- Options: DC 12V (±25%) or PoE (IEEE 802.3af)
- Power Consumption: Maximum 7W
- Dimensions: Diameter 118 mm × Height 95 mm (4.6″ × 3.7″)
- Weight: Approximately 0.30 kg (0.66 lb)
- Material: Combination of metal and plastic
- Operating Environment: Temperature range from -30°C to 60°C (-22°F to 140°F); humidity up to 95% RH (non-condensing)
- Ingress Protection Rating: IP67, indicating high resistance to dust and water
