Description
The Huawei eKitEngine S220-48T4S is a Layer 2 Smart Managed Gigabit Switch designed for small and medium-sized businesses, enterprise branch offices, educational institutions, hotels, retail stores, and campus networks. Equipped with 48 Gigabit Ethernet RJ45 ports and 4 Gigabit SFP uplink ports, it provides reliable high-speed access connectivity with flexible fiber uplinks for enterprise and business networking.
The switch supports a complete range of intelligent Layer 2 management features, including VLAN, QoS, ACL, Link Aggregation (LACP), STP/RSTP/MSTP, ERPS, IGMP Snooping, DHCP Snooping, IPv6, and advanced security capabilities. These features ensure high network availability, efficient traffic management, and secure access for business-critical applications.
With Huawei eKit Cloud Management, administrators can remotely deploy, configure, monitor, and troubleshoot the switch using the Huawei eKit App, Web GUI, CLI, or SNMP. This simplifies network operations while reducing maintenance costs.
The S220-48T4S features a built-in AC power supply, intelligent fan cooling, and a durable 1U rack-mount metal chassis, making it an excellent solution for enterprise LANs, branch offices, campus access networks, and network aggregation where PoE functionality is not required.
Specifications
| Feature | Specification |
|---|---|
| Model | Huawei eKitEngine S220-48T4S |
| Product Type | Layer 2 Smart Managed Gigabit Switch |
| Ethernet Ports | 48 × 10/100/1000BASE-T RJ45 |
| Uplink Ports | 4 × 1GE SFP |
| PoE Support | No |
| Switching Capacity | 104 Gbps |
| Packet Forwarding Rate | 77 Mpps |
| MAC Address Table | 16K Entries |
| VLAN Support | Up to 4,094 VLANs |
| QoS | Supported |
| ACL | Supported |
| Link Aggregation | LACP |
| Spanning Tree Protocol | STP, RSTP, MSTP |
| Ring Protection | ERPS |
| Multicast | IGMP Snooping |
| IPv6 | Supported |
| DHCP Features | DHCP Snooping |
| Management | Web GUI, CLI, SNMP, Huawei eKit App, Cloud Management |
| Power Supply | Built-in AC (90–264V AC, 45–65Hz) |
| Cooling | Intelligent Fan Cooling (1 Built-in Fan) |
| Installation | Rack Mount, Desktop, Wall Mount |
| Chassis Material | Metal |
| Dimensions (H × W × D) | 43.6 × 442 × 220 mm |
| Weight | 2.71 kg |
| Operating Temperature | -5°C to +50°C |
