Description
S110-16T2S
Product Specifications
Specifications eKitEngine S110-8T2ST eKitEngine S110-8P2ST
Switching capacity 20 Gbit/s 20 Gbit/s
Packet forwarding rate 14.88 Mpps 14.88 Mpps
Downlink port 8 x 10/100/1000BASE-T ports 8 x 10/100/1000BASE-T PoE+ ports
Uplink port 1 x GE electrical port, 1 x GE SFP port 1 x GE electrical port, 1 x GE SFP port
MAC address entry 4K MAC address entries 4K MAC address entries
Dimensions (H x W x D) 35 mm x 210 mm x 130 mm 35 mm x 210 mm x 130 mm
Weight 0.40 kg 0.91 kg
Input voltage 12 V 54 V
Maximum power consumption 8 W
⚫ Without PoE: 10 W
⚫ With PoE: 158 W (PoE: 124 W)
Long-term operating temperature
0°C to 40°C (0 m to 1800 m) 0°C to 40°C (0 m to 1800 m)
Storage temperature –40°C to +70°C –40°C to +70°C
Operating humidity 5% to 95% 5% to 95%
Service port surge protection ±4 kV ±4 kV
Working mode Three working modes: standard mode, port isolation and flow control disabling
Heat dissipation mode Fanless, natural heat dissipation Fanless, natural heat dissipation
