Description
The Huawei eKitEngine S220-48P4S is a Layer 2 Smart Managed Gigabit PoE+ Switch designed for small and medium-sized businesses, enterprise offices, educational institutions, hotels, retail stores, and IP surveillance deployments. It provides 48 Gigabit PoE+ Ethernet ports and 4 Gigabit SFP uplink ports, delivering reliable wired connectivity with flexible fiber uplinks for scalable business networks.
Featuring a 380W PoE power budget, the switch powers IEEE 802.3af/at-compliant devices such as IP cameras, wireless access points, VoIP phones, and access control systems directly through Ethernet cables, reducing installation costs and simplifying network deployment.
The S220-48P4S includes comprehensive Layer 2 features such as VLAN, QoS, ACL, Link Aggregation (LACP), STP/RSTP/MSTP, ERPS, IGMP Snooping, DHCP Snooping, IPv6, and advanced security functions. It also supports Huawei eKit Cloud Management, allowing administrators to configure, monitor, and troubleshoot the switch remotely through the Huawei eKit App or Web interface.
Its built-in AC power supply, intelligent fan cooling, and durable 1U rack-mount metal chassis make it an excellent solution for enterprise access networks requiring dependable PoE performance and simplified management.
Specifications
| Feature | Specification |
|---|---|
| Model | Huawei eKitEngine S220-48P4S |
| Switch Type | Layer 2 Smart Managed PoE+ Switch |
| Downlink Ports | 48 × 10/100/1000BASE-T RJ45 (PoE+) |
| Uplink Ports | 4 × 1GE SFP |
| PoE Standard | IEEE 802.3af / IEEE 802.3at (PoE+) |
| Total PoE Budget | 380 W |
| Switching Capacity | 104 Gbps |
| Packet Forwarding Rate | 77 Mpps |
| MAC Address Table | 16K Entries |
| VLAN Support | Up to 4,094 VLANs |
| QoS | Supported |
| ACL | Supported |
| Link Aggregation | LACP |
| Spanning Tree | STP, RSTP, MSTP |
| Ring Protection | ERPS |
| Multicast | IGMP Snooping |
| IPv6 | Supported |
| DHCP Features | DHCP Snooping |
| Management | Web GUI, CLI, SNMP, Huawei eKit App, Cloud Management |
| Power Supply | Built-in AC (100–240V AC, 50/60Hz) |
| Cooling | Intelligent Fan Cooling |
| Installation | 1U Rack Mount |
| Operating Temperature | -5°C to +50°C |
