Description
Specifications
| Specification | Details |
|---|---|
| Model | HPE JD119A / JD119B Compatible |
| Product Type | SFP Fiber Optic Transceiver |
| Form Factor | SFP (Small Form-Factor Pluggable) |
| Ethernet Standard | 1000BASE-LX |
| Data Rate | 1.25 Gbps |
| Connector Type | Duplex LC/UPC |
| Fiber Type | Single-Mode Fiber (SMF) |
| Wavelength | 1310 nm |
| Maximum Distance | Up to 10 km |
| Optical Interface | LC Duplex |
| Transmission Mode | Full Duplex |
| Digital Diagnostic Monitoring | Supported (DDM/DOM) |
| Hot Swappable | Yes |
| IEEE Standard | IEEE 802.3z 1000BASE-LX |
| Power Consumption | ≤ 1W |
| Operating Temperature | 0°C to 70°C |
| Compatibility | HPE, Aruba, HP Networking Switches and Routers with SFP Ports |
| Applications | Enterprise Networks, Campus Networks, Fiber Backbone Links, Data Centers |
The module supports Gigabit Ethernet over single-mode fiber using a 1310nm wavelength and transmission distances up to 10km through LC duplex connectors. -swappable SFP form factor** enables easy installation and replacement without interrupting network operations. make it an ideal solution for extending Gigabit Ethernet connections across buildings, campuses, and fiber backbone infrastructures. seeking scalable and high-performance network infrastructure.
