Name: Grandstream HT814 V2 Powerful 4 Port FXS Gateway with Gigabit NAT Router | Peta Store
Brand: Grandstream

Description

HT814 V2

Supports 2 SIP profiles through 4 FXS ports and dual Gigabit ports
Includes a built-in NAT router which can handle routing speeds up to 100MBps
TLS and SRTP security encryption technology to protect calls and accounts
LED Indicators – POWER, NET1, NET2, PHONE1, PHONE2, PHONE3, PHONE4
Automated provisioning options include TR-069 and XML config files
Supports 3-way voice conferencing
Failover SIP server automatically switches to secondary server if main server loses connection
Supports T.38 Fax for creating Fax-over-IP
Supports a wide range of caller ID formats
Use with Grandstream’s UCM series of IP PBXs for Zero Configuration provisioning

Category	Details
Lines	4 Lines
Audio Conferencing	3-Way Voice Conferencing per Port
Telephone Interfaces	Four (4) RJ11 FXS ports; can be expanded by peering with an FXS gateway
Network Interfaces	Two (2) 10/100/1000Mbps RJ45 ports
LED Indicators	Power, Net1, Net2, Phone1, Phone2, Phone3, Phone4
Telephony Features	Caller ID display or block, Call Waiting, Flash, Blind or Attended Transfer, Call Forward, Hold, Do Not Disturb, 3-Way Conference
Fax Over IP	T.38 compliant Group 3 Fax Relay up to 14.4 kbps and auto-switch to G.711 for Fax Pass-through

Additional information

Audio / Voice Quality	Standard Voice
Bluetooth & WIFI	Not Supported
Concurrent Calls	4 Concurrent Calls
Display Type	Non-Display
FXO Ports	None
FXS Ports	4 Ports
Management Platform	GDMS Networking (Cloud), Local Web GUI
Mounting Options	Desktop
POE	Not Support POE
Ports	2 Ports
Ports Speed	1G
Video Conferencing	Not Supported
