Description
The Cisco C9200L-48P-4X-E is built to provide secure, scalable, and resilient enterprise networking for modern business infrastructures. Equipped with 48 Gigabit Ethernet PoE+ ports and 4 fixed 10G SFP+ uplink interfaces, it enables high-performance connectivity for wireless access points, IP phones, surveillance cameras, IoT devices, and enterprise network equipment.
As part of the Cisco Catalyst 9200L Series, the switch extends Cisco’s intent-based networking architecture with advanced Layer 3 capabilities, intelligent traffic management, network segmentation, QoS, IPv4/IPv6 routing, and enterprise-grade security. Powered by Cisco Network Essentials software, it simplifies network operations while maintaining high levels of performance and reliability.
The integrated PoE+ functionality allows both power and data transmission through a single Ethernet cable, reducing deployment costs and simplifying infrastructure design. With a substantial PoE budget and support for Cisco StackWise technology, the switch enables scalable growth and centralized management across enterprise environments.
Designed for enterprise campuses, branch offices, education, healthcare, hospitality, and secure business networks, the C9200L-48P-4X-E delivers operational resiliency, advanced security, and future-ready networking performance.
Specifications
| Specification | Details |
|---|---|
| Model | Cisco C9200L-48P-4X-E |
| Product Series | Cisco Catalyst 9200L Series |
| Software License | Network Essentials |
| Switch Type | Managed Layer 3 Switch |
| Ports | 48 × Gigabit Ethernet PoE+ |
| Uplink Ports | 4 × 10G SFP+ |
| PoE Standard | IEEE 802.3af/at PoE+ |
| PoE Support | Yes |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 261.9 Mpps |
| Layer Support | Layer 2 / Layer 3 |
| Routing Features | Static Routing, OSPF, RIP, IPv4/IPv6 |
| VLAN Support | Yes |
| QoS Support | Advanced QoS |
| Security Features | ACL, 802.1X, MACsec, TrustSec |
| IPv6 Support | Yes |
| Stacking Support | Cisco StackWise-160 |
| Stacking Bandwidth | Up to 160 Gbps |
| DRAM | 2 GB |
| Flash Memory | 4 GB |
| Management | CLI, SNMP, Cisco DNA Center |
| Power Supply | Internal, Redundant PSU Supported |
| Mounting Type | Rack Mountable |
| Application | Enterprise Networks, VoIP, CCTV, Wireless Networks |
| Brand | Cisco |
Key Features
- 48 Gigabit Ethernet PoE+ ports
- 4 fixed 10G SFP+ uplinks
- Cisco Network Essentials software
- Enterprise Layer 3 managed switching
- Advanced MACsec and TrustSec security
- IPv4 and IPv6 routing support
- Cisco StackWise-160 scalability
- High-performance switching architecture
- Redundant power supply support
- Ideal for campus and branch deployments
