Description
R2W97A
R2W97A Specification |
|
|
Radios |
Dual radio for simultaneous dual-band operation
5 GHz 802.11ac 2×2 MIMO for up to 867 Mbps wireless data rate, with Multi User MIMO support (Wi-Fi 5) 2.4 GHz 802.11n 2×2 MIMO for up to 300 Mbps wireless data rate (Wi-Fi 4) |
|
Interfaces |
Uplink Gigabit Ethernet port, with PoE-in support (802.3af)
DC power connector (12V) Bluetooth Low Energy (BLE) radio LED status indicators (2) Reset/LED control button Kensington security slot |
|
Antennas |
Integrated down-tilt omni-directional antennas with maximum individual antenna gain of 3.3dBi in 2.4GHz and 5.8dBi in 5GHz |
|
Dimension |
152mm x 152mm x 34mm, excluding mount accessories |
|
Power |
Power over Ethernet (POE): 802.3af (class 3)
Max power consumption (worst-case): 10.1W (PoE), 8.8W (DC) DC power (12V) Note: Power sources are sold separately |
|
Mounting |
The access point ships with a (black) mount clip to attach to suspended ceiling rails, and a (white) mount clip to attach to solid surfaces (wall/ceiling) |
|
Environmental & reliability |
Operating temperature: 0° C to +40° C (+32° F to +104° F)
MTBF: 795khrs (91yrs) at +25° C |
|
Industry certifications |
UL 2043 plenum rating
EN 60601-1-1 and EN 60601-1-2 (for deployment in medical environments) Wi-Fi Alliance certified (WFA) 802.11ac with Wave 2 (Wi-Fi 5), WPA2, WPA3 |
|
Management options |
Instant On mobile application (Android & iOS)
Cloud Portal: Portal.ArubaInstantOn.com |
