Description
ZKBio710
Features :
· All-in-one POS with 15″ True-Flat PCAP Touch Screen
· 15″ True-Flat PCAP Front Touch Screen with Splash-Proof Protection
· Stylish and Compact Design, Available in Black and Gray & White
· Modular Design Built-in with Fingerprint Module, 2D Barcode Scanning Module and MSR
· Hidden Cable Management
· Fanless System with Innovative Heat Pipe Design
· Comprehensive After-Sale Services
· UV Effect Paint Craft
Parameters :
- Model Name
ZKBio710
ZKBio730
ZKBio750
- Printing method
ZKBio710 : Intel® Celeron® J1900 @ 1.99GHz Optional: Intel ®Celeron® J6412 @ 2.00GHz
ZKBio730 : Intel ®Core ®i3-6100U @ 2.40GHz
ZKBio750 : Intel® Core® i5-6200U @ 2.30GHz
- Memory
4GB RAM Standard, DDR3 & DDR4, Up to 8GB
64GB SSD Standard, Up to 512GB
Optional: External Memory Slots (M.2 SATA SSD 120GB & HDD 500GB )
- Display
Configuration 1: Main: 15″ HD, 1024*768, Capacitive Touch Screen; Second: LED (8C digital tube)
Configuration 2: Main: 15″ HD, 1024*768, Capacitive Touch Screen; Second: VFD (2*20 lines)
Configuration 3: Main: 15″ HD, 1024*768, Capacitive Touch Screen; Second: 9.7″ LCD HD, 1024*768
Configuration 4: Main: 15″ HD, 1024*768, Capacitive Touch Screen; Second: 15″ LCD HD, 1024*768
- Material
Aluminum alloys, ABS
- Colour
Black and Gray, White (Optional)
- Operating System
Support Windows 7, 8, 10, 11
- Dimension
346*190*402mm
- Packing Dimensions
405*300*450mm
- Net Weight
Configuration 1&2: 5.4Kg
Configuration 3: 6.3Kg
Configuration 4: 7.8Kg
- Gross Weight
Configuration 1&2: 7Kg
Configuration 3: 7.9Kg
Configuration 4: 9.3Kg
- Interfaces
ZKBio710 ：1* USB 3.0 / 5* USB 2.0 / 1* RJ45 LAN port / 1* COM port / 1* VGA port / 1* Audio jack / 1* MIC IN / 1* Power port
ZKBio730：4* USB 3.0 / 2* USB 2.0 / 2* COM port / 1* VGA port / 1* HDMI port / 1* RJ45 LAN port / 1* Audio jack / 1* MIC IN / 1* Power port
ZKBio750 : 4* USB 3.0 / 2* USB 2.0 / 2* COM port / 1* VGA port / 1* HDMI port / 1* RJ45 LAN port / 1* Audio jack / 1* MIC IN / 1* Power port
- Power Supply
DC12V/5A
- WiFi
Single-band 2.4GHz (Optional)
Dual-band 2.4GHz/5GHz (Optional)
- Bluetooth
Not Support
- Options & Peripherals
Built-in fingerprint module
Built-in 2D barcode scanning module
Built-in MSR reader
Built-in RFID reader
- Operating Temperature
0°C ~ 40°C at 20% ~ 80% Humidity
- Storage Temperature
-15°C ~ 60°C at 20% ~ 80% Humidity
- Certifications
ISO9001, CE, FCC, RoHS
