Description
X628-TC
> X628 – TC is an innovative biometric fingerprint reader for time and attendance applications, delivering unparalleled performance using an advanced algorithm for excellent reliability, accuracy and matching speed.
X628 – TC features the fastest commercial-based fingerprint matching algorithm and a high-performance, high-quality optical fingerprint sensor from ZK. The 3-inch TFT display can display more information clearly, including fingerprint image quality, verification results, etc.
TCP/IP connection is standard and make sure that the data transfer between the device and PC can be easily done within several seconds.
specifications
| Fiingerprint Capacity: | 3000 templates |
| Transaction Capacity: | 100,000 |
| Hardware Platform: | ZEM510 |
| Sensor: | ZK Optical Sensor |
| Algorithm Version: | ZK Finger v10.0 |
| Communication: | RS232/485 TCP/IP |
| Standard Functions: | Workcode, SMS, DLST, Scheduled-bell, Self-Service, Query, Automatic status switch |
| Optional Functions: | ID, Mifare, HID, USB-host, Webserver, printer, 9 digit user ID |
| Display: | 3 inches TFT Screen |
| Power Supply: | 5V DC 2A |
| Operating temperature: | 0 C – 45 C |
| Operating Humidity: | 20% – 80% |
| Dimension: | 190X142X53 mm |
| Weight: | 0.85 kg |
