Description
MFB-TFX
Key Features :
- SFP Multi-Source Agreement compliant
- 125Mbps IEEE 802.3u 100Base-FX compliant
- Industry standard small form pluggable (SFP) package (for model MFB-TFX / MFB-TF20 )
- 125Mbps FDDI ISO / IEC 9314-1 compliant
- Serial ID functionality support
- AC-coupled differential inputs and outputs
- Class 1 laser safety standard IEC 825 compliant
- 2km link on a multimode fiber and 20km to 60km on a single mode fiber
- Low power dissipation
- 0 to 60 degrees C operating temperature for MFB-FX / MFB-F20 / MFB-F40 / MFB-F60 / MFB-FA20 / MFB-FB20
- -40 to 85 degrees C operating temperature for MFB-TFX / MFB-TF20 /MFB-TF120/MFB-TSA & MFB-TSB/MFB-TFA20 & MFB-TFB20/MFB-TFA40 & MFB-TFB40/MFB-TFA60 & MFB-TFB60
MFB-TFX Applications :
The MFB family SFP Fast Ethernet transceivers can be installed in PLANET Switch and Media Converter products with 100Base-FX SFP interface. The deployment distance can be extended from 2km (Multi-Mode, LC) up to 60 kilometers (Single-Mode, LC).
The MFB family SFP Fast Ethernet transceivers are hot-pluggable and hot-swappable. You can plug in and pull out the transceivers to / from any SFP port without having to power off the Switch / Media Converter.
MFB-TFX
The MFB-T 100Base-FX transceiver series is an ideal solution for -40℃ to 85℃ wide temperature industrial equipment with 100Base-FX SFP interfaces. The deployment distance can be extended from 2km (Multi-Mode, LC) up to 20km (Single-Mode, LC).
MFB-TFX
