Planet Industrial Switch DIN-Rail L2+/L3 Manageable Industrial Gigabit POE Switch-(IGS-5225-8P2S2X)
the IGS-5225-8P2S2X can easily build a power centrally controlled for IP phone system, IP camera system, or wireless AP group for Industrial network.
Description
Industrial Area Department/Workgroup PoE Switch
Providing up to 8 PoE+, in-line power interfaces, the IGS-5225-8P2S2X can easily build a power centrally controlled for IP phone system, IP camera system, or wireless AP group for Industrial network. For instance, 8 PoE IP cameras or wireless access points can be easily installed around the corner in the industrial environment for surveillance demands or for a wireless roaming network. Without the power-socket limitation, the makes the installation of IP cameras or wireless AP easier and more efficient.
Excellent 10Gbps High Bandwidth Solution to Core Network
performs 66Gbps non-blocking switch fabric, so it can easily provide a local 10Gbps high bandwidth Ethernet network for the backbone of your department. With the two built-in SFP+ ports, provides the uplink to the backbone network through the 10G Ethernet LR/SR SFP+ modules. It further improves the network efficiency and protects the network clients by offering the security and QoS features.
Layer 3 VLAN Routing and 10G Uplink Application
With the built-in, robust Layer 3 routing protocols, ensures reliable routing between VLANs and network segments. The routing protocols can be applied by VLAN interface with up to 32 routing entries. The, certainly an ideal solution for industries, offers greater security, control and bandwidth conservation, and high-speed uplink.
Additional information
| Access Ports | 8 |
|---|---|
| Access Ports Speed | 1 G (RJ-45) |
| Forwarding Rate (Throughput) | 49 Mpps |
| Management Platform | |
| Mounting Options | DIN‑rail, wall mount |
| POE | Support POE |
| POE Budget | |
| Switch Layer | Layer 3 |
| Switching Capacity | 68 Gbps |
| Uplink Ports | 4 |
| UpLinks Speed | 1G, 2.5G, 10G |
