Description
IPC3612LB-ADF28K-G
Key Features:
The IPC3612LB-ADF28K-G is a 2MP HD IR Fixed Eyeball Network Camera designed for high-quality surveillance applications.
- High-Resolution Imaging: Equipped with a 1/2.7″ CMOS sensor, it delivers clear images at 2MP (1920×1080) resolution at 30/25 frames per second (fps).
- Advanced Video Compression: Supports Ultra H.265, H.265, H.264, and MJPEG compression standards, optimizing storage and bandwidth usage.
- Built-in Microphone: Features an integrated microphone for audio recording capabilities.
- Smart IR Technology: Provides infrared illumination up to 30 meters (98 feet), ensuring effective night-time surveillance.
- Day/Night Functionality: Includes an IR-cut filter with automatic switching (ICR) to maintain image quality across varying lighting conditions.
- Digital Noise Reduction: Utilizes 2D/3D DNR (Digital Noise Reduction) to enhance image clarity in low-light environments.
- Local Storage Support: Supports micro SD cards for local storage options.
- Power Options: Operates on DC12V or Power over Ethernet (PoE) (IEEE 802.3af) for flexible installation.
- Durability: Boasts IP67-rated weatherproofing and IK10-rated vandal resistance, making it suitable for various environmental conditions.
- Adjustable Mounting: Offers 3-axis adjustment (pan: 0° ~ 360°, tilt: 0° ~ 80°, rotation: 0° ~ 360°) for flexible installation and optimal coverage.
Specifications:
- Lens Options: 2.8mm @F2.0 or 4.0mm @F2.0.
- Field of View:
- 2.8mm lens: Horizontal: 112.9°, Vertical: 59.1°, Diagonal: 121.2°.
- 4.0mm lens: Horizontal: 91.2°, Vertical: 47.9°, Diagonal: 95.9°.
- DORI Distances:
- 2.8mm lens: Detect: 42.0m, Observe: 16.8m, Recognize: 8.4m, Identify: 4.2m.
- 4.0mm lens: Detect: 60.0m, Observe: 24.0m, Recognize: 12.0m, Identify: 6.0m.
- Video Output: Main Stream: 1080P (1920×1080) at up to 30fps; Sub Stream: 720P (1280×720) at up to 30fps.
- Minimum Illumination: Color: 0.01 lux (F2.0, AGC ON); 0 lux with IR on.
- Shutter Speed: Auto/Manual, 1 ~ 1/100000s.
- Signal-to-Noise Ratio (S/N): >52dB.
- Wide Dynamic Range (WDR): 120dB true WDR technology enables clear images in strong light scenes.
- Power Supply: DC12V ±25% or PoE (IEEE 802.3af).
- Power Consumption: Max 5.0W.
- Operating Conditions: Temperature: -30°C to 60°C (-22°F to 140°F); Humidity: ≤ 95% RH (non-condensing).
- Dimensions: Φ118 × 95mm (4.65” × 3.74”).
- Weight: 0.3 kg (0.66 lbs).
This camera is ideal for both indoor and outdoor surveillance, offering high-definition video and advanced features for reliable security monitoring.
