Description
DES-1005C
DES-1005C Specification
|
Auto MDI/MDIX
|
Yes |
|---|---|
|
Control
|
802.3x Flow |
|
Dimensions
|
88x48x21.45mm |
|
Energy Efficiency Ethernet (EEE)
|
Yes |
|
FAN
|
Fanless |
|
Head-of-line (HOL) Blocking Prevention
|
Yes |
|
Interfaces
|
5 x 100Base-TX |
|
Jumbo Frame
|
2048 Bytes |
|
MAC Address Table Size
|
2,000 |
|
Max. Packet Forwarding Rate
|
0.74 Mpps |
|
Maximum Heat Dissipation
|
0.406 BTU/h |
|
Maximum Power Consumption
|
0.784 W |
|
MTBF
|
1,785,631 hours |
|
Operating Humidity
|
10% ~ 90% RH |
|
Operating Temperature
|
0 ~ 40 °C |
|
Packet Buffer Size
|
96KBytes |
|
Power Input
|
DC: 5V, 0.55A |
|
Power Saving By Link Status
|
YES |
|
Standby Power Consumption
|
0.4 W |
|
Storage Humidity
|
5% ~ 95% RH |
|
Storage Temperature
|
– 40 ~ 70 °C |
|
Store & Forwarding Forwading
|
Yes |
|
Switching Capacity
|
1 Gbps |
|
Weight
|
434 g |
Fast Networking Made Easy
With data transfer speeds of up to 200 Mbps at full duplex, these switches are ideal for quick file transfers, online gaming and smooth streaming media. They feature easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto MDI/MDIX crossover makes connection a cinch; just plug in your cables and you’re ready to go.
Economical, Plug-and-play Networking Switch
The DES-1005C 10/100 Mbps Unmanaged Switch is an economical, plug-and-play networking switch for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Fast Ethernet. It gives you five 10/100 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity.
Reliable Plug and Play Installation
The DES-1005C is a Plug-and-Play device that requires no configuration, so setup is simple and hassle-free, and you can easily connect multiple computers, share files, music, and video across your home or small office network, or even create a multiplayer gaming environment. 802.3x flow control on each port minimizes dropped packets when the port’s receiving buffer is full, giving you a more reliable connection for all of your connected devices.
