C9300X-12Y-A Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage

C9300X-12Y-A

Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage

WhatsApp Button Call for Price

Compare
Availability: Available on backorder
SKU:C9300X-12Y-A

All prices include VAT

Description

C9300X-12Y-A

Overview

The C9300X-12Y-A is a Catalyst 9300 switch model by Cisco. This model comes with 12 ports of 25G/10G/1G SFP28 and modular uplinks. It is part of the Cisco Catalyst 9300 Series, which provides flexible deployment options, including small to medium-sized businesses, enterprise branches, and campuses. The switch includes advanced security features and is powered by Cisco’s IOS XE software.

Quick Spec

Table 1 shows the quick spec of the C9300X-12Y-A.

Product Code C9300X-12Y-A
Manufacturer Cisco
Type Network Switch
Ports 12 x 25G/10G/1G SFP28
Uplinks Modular
Software Network Advantage

Specification

C9300X-12Y-A Specifications

Model C9300X-12Y-A
Product Description Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage
Ethernet Ports 12 x SFP28
Uplink Slots Modular
Uplink Speeds 25G/10G/1G
Switching Capacity 480 Gbps
Forwarding Rate 357.14 Mpps
Power Supply Internal
Dimensions 17.5 x 16.1 x 1.7 in.
Weight 13.9 lbs
Operating Temperature 23 to 113��F
Operating Humidity 10 to 90%
OS Cisco IOS XE

Product Features

  • Flexibility: 12 ports of 25G/10G/1G SFP28 and modular uplinks provide a variety of connectivity options.
  • Security: Advanced security features such as secure boot, Trustworthy Systems, MACsec, and other capabilities.
  • Efficiency: Supports Energy Efficient Ethernet (EEE) and lower power consumption.
  • Scalability: Designed to scale as network demands grow, with high-density stacking capabilities.

Product Applications

  • Small to Medium-Sized Businesses: Provides secure and scalable connectivity options.
  • Enterprise Branches: Delivers enterprise-grade performance and security.
  • Campuses: Handles high-density deployments with advanced security features.

Supported Options

Table 2 shows the supported options of the C9300X-12Y-A.

Model Accessory
C9300-NM-8X 8x 10GE Network Module
PWR-C1-1100WAC= 1100W AC Config 1 Power Supply
STACK-T1-50CM= Cisco STACK-T1-50CM= StackWise-480 50cm stacking cable

Compare to Similar Items

Table 3 shows the comparison to similar items of the C9300X-12Y-A.

Model Difference
C9300X-24Y-A Offers 24 ports of 25G/10G/1G/100M SFP28 and 4 ports of 40/100G QSFP28
C9300X-48Z-A Offers 48 ports of 25G/10G/1G/100M SFP28 and 4 ports of 40/100G QSFP28

Ordering Information

Table 4 shows the ordering information of the C9300X-12Y-A.

Product Code Description
C9300X-12Y-A Catalyst 9300 12-port 25G/10G/1G SFP28 with modular uplinks, Network Advantage
