Description
Features
- Full the requirements of Category 6, Class E (250MHz) according to the present standard of the ISO/IEC 11801.
- Each individual patch cord is tested and marked with a quality stamp.
- Can also use as Cat5e (backward compatible).
- Strain relief is provided with wide function.
- Labeling possible on the strain relief or on the color-coding.
- The impedance of 100 ohms.
- LSZH version
| Specification | Details |
|---|---|
| Model | PL-PC-U6-5G |
| Brand | ProLink |
| Product Type | Cat6 U/UTP Patch Cord |
| Cable Category | Category 6 (Cat6) |
| Shielding | Unshielded (U/UTP) |
| Wiring Standard | T568B |
| Length | 5 Meters |
| Color | Gray |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Frequency Support | Up to 250 MHz |
| Impedance | 100 Ohms |
| Connector Type | RJ45 to RJ45 |
| Contact Material | Phosphor Bronze (CuSn6) |
| Contact Plating | 0.7 μm Selective Gold Plating |
| Plug Housing | Polycarbonate |
| Current Rating | 1.5A Maximum @ 25°C |
| Voltage Rating | 150 VAC Maximum |
| Dielectric Withstanding Voltage | 1000 VAC for 1 Minute |
| Insulation Resistance | 250 MΩ Minimum |
| Operating Temperature | -10°C to +60°C |
| Standards Compliance | ISO/IEC 11801 Class E, IEC 60603-7 |
| Compatibility | Cat6 and Backward Compatible with Cat5e |
| Applications | Patch Panels, Switches, Routers, Workstations, Structured Cabling Systems |
