Description
The Cisco C9200-24T-A is part of the Cisco Catalyst 9200 Series, extending the power of intent-based networking to enterprise access deployments. Built for modern organizations, the switch combines security, resiliency, and operational simplicity with advanced Layer 3 capabilities.
Featuring 24 Gigabit Ethernet data ports, the switch provides reliable wired connectivity for desktops, servers, printers, and network devices. Its modular uplink architecture allows organizations to customize uplink connectivity with optional network modules, providing flexibility for future network growth and evolving infrastructure requirements.
Powered by Cisco Network Advantage licensing, the switch supports advanced Layer 3 routing protocols including OSPF, EIGRP, BGP, VRF, multicast routing, policy-based routing, and network segmentation. These capabilities help organizations build scalable and secure enterprise networks.
Running Cisco IOS XE, the C9200-24T-A supports automation, programmability, telemetry, and Cisco DNA Center integration, enabling centralized management and simplified network operations. Cisco StackWise technology provides scalable stacking capabilities for improved resiliency and operational efficiency.
Advanced security features such as MACsec encryption, Secure Boot, TrustSec, Access Control Lists (ACLs), and IEEE 802.1X authentication help protect business-critical infrastructure against evolving cyber threats.
The Cisco C9200-24T-A is ideal for enterprise campuses, branch offices, government organizations, healthcare facilities, educational institutions, and corporate environments requiring reliable and secure access-layer networking.
Specifications
| Specification | Details |
|---|---|
| Model | Cisco C9200-24T-A |
| Product Series | Cisco Catalyst 9200 Series |
| Software License | Network Advantage |
| Switch Type | Managed Layer 3 Switch |
| Ports | 24 × 10/100/1000 Gigabit Ethernet Data Ports |
| Uplink Support | Modular Network Uplink Module |
| PoE Support | No |
| Layer Support | Layer 2 / Layer 3 |
| Routing Features | OSPF, EIGRP, BGP, VRF, Static Routing |
| Switching Capacity | Up to 128 Gbps |
| Forwarding Rate | Up to 190.4 Mpps |
| VLAN Support | Yes |
| QoS Support | Advanced QoS |
| Security Features | MACsec, TrustSec, ACL, 802.1X |
| IPv4 Support | Yes |
| IPv6 Support | Yes |
| Operating System | Cisco IOS XE |
| Stack Support | Cisco StackWise-160 |
| Stacking Bandwidth | 160 Gbps |
| Management | CLI, SNMP, Cisco DNA Center |
| Power Supply | Internal |
| Form Factor | Rack Mountable |
| Application | Enterprise Access, Campus Networks, Branch Offices |
| Brand | Cisco |
Key Features
- 24 Gigabit Ethernet data ports
- Cisco Network Advantage license
- Modular uplink architecture
- Advanced Layer 3 routing protocols
- Cisco StackWise-160 support
- Cisco DNA Center integration
- Enterprise-grade security features
- MACsec and TrustSec support
- High availability and resiliency
- Ideal for enterprise access deployments
